Warm Isostatic Press D500-L2000/P200mpa-T300

Item Code:D500-L2000/P200mpa-T300 Features:
  • Description

D500-L2000/P200mpa-T300
Diameter of Vessel: 500mm
Length of Vessel: 2000mm
Press: 200mpa
Temperature: 300 degrees

1. The vessel inner materials of WIP is 34CrNi3MoV alloy whole parts forged and then The forged vessel be wire wounded by alloy of wire(65Mn steel 1.5mm x 6mm size) as per the designed.

2.Whole procedure of the warm isostatic press machine (WIP ) , increasing, holding and releasing pressure is controlled by PLC and also there is a decompression system to protect the system over pressure to keep the machine in safety running.

3.  We would like to send our technicians to guide the installation and training workers for operation the machine.

4.We will supply one set of spare parts together with the machine free of charges.

"SUOHAIPU"is a leading manufacturer dedicated to research, development and manufacturing of CIP and WIP machine, famous with high- efficient R&D and technical breakthrough.

We offer comprehensive service for global clients before and after sales. Our technical support before sales includes test pressings at our plant, technical evaluation and preliminary product design based on customer specific demand. If necessary, we would like to send our technicians to the client’s plant to guide the installation and training the workers for operation the machine.
