cold isostatic press 1000/3500-200

Item Code:1000/3500-200 Features:
  • Description

Diameter of Pressure Vessel: 1000  mm

Depth of Pressure Vessel: 3500  mm

Maximum Isostatic Pressure: 200   Mpa
1. The vessel inner materials is 34CrNi3MoV alloy whole parts forged and then The forged vessel be wire wounded by alloy of wire(65Mn steel 1.5mm x 6mm size) as per the designed.
2.Whole procedure of the cold isostatic pressing (Cold Isostatic Press ), increasing, holding and
releasing pressure is controlled by PLC and also there is a pressure decompression system to protect the system over pressure to keep the machine in safety running.
3. The pressuring system is Hydraulic System. The hydraulic oil is anti-abraded oil, HM-32 for the hydraulic system. And in the vessel, the liquid is chloridized water to proof-rusting and corrosive.
4. We will supply one set of spare parts together with the machine free of charges.

 "SUOHAIPU"is a leading manufacturer dedicated to research, development and manufacturing of cold isostatic press machine, famous with high- efficient R&D and technical breakthrough.
  We offer comprehensive service for global clients before and after sales.Our technical support before sales includes test pressings at our plant, technical evaluation and preliminary product design based on customer specific demand. If necessary, we would like to send our technicians to the client’s plant to guide theinstallation and training the workers for operation the machine.
